HTV Silicone Overmold Epoxy

Product Specification:
Model No. : CL-24S-2D
Minimum Order Quantity :   1 Litter
Lead Time:7-10 Days
Payment Terms:   T/T , Western Union , Paypal
Package:   1L/Bottle
Tel: +86.755.8147.8876
Fax: +86.755.8147.8872


HTV Silicone Overmold Epoxy




CL-24S-2D, Silicone primer to bond peroxide-cure silicone rubber with substrates like Epoxy, stainless steel, aluminum, copper, PA, bakelite, zinc-coated or nickel coated metal.

silicone insulator






Product Specifications



Appearance :Transparent liquid

Density(25 cm³):0.80g/cm³

Hazard Classification:None Hazard

Break down Voltage(Attach 4mm Silicone sleeve):30KV/C㎡

Temperature tolerance:-60~180℃

Shear Strength:11KG/ C㎡







1, Treat the substrates with blast sanding, polishing or wash with industrial alcohol.

2, Brushing, painting, dipping or spraying the CL-24S-2D on the substrates.

3, Leave dry in room temp for 30 minutes or baking at 110-130℃ for 5-15mintes.

4, The primer treated substrates are processed within that day.

5, The first cure is suitable to DBPH system silicone rubber and the second cure the temperature maximum at 200℃.







1, Please cap its cover immediately after use to avoid volatilization.

2, Store the used and unused adhesive in separate way to lengthen the shelf life.

3, After the primer coated on the substrates, leave it volatilize completely before entering the mold, otherwise, there will be bubbles in the finished products.

4, Wash clean the substrates to remove dirts or oil to avoid bad adhesion.

5, Flush with water quickly once  contacting with eyes accidently during use.






Sorry,Here is the product description, there is no data!
Sorry,Here is the product notes, there is no data!

TDS: CL-24S-2D
